Different Protocols explained

Cover Image for Different Protocols explained
Shivam Sourav Jha
Table of Contents

Table of Contents

  1. Unraveling the Mystery of Protocols

    • The Role of Protocols in Network Communication

    • Examples: HTTP, SMTP, RESP, POP3, IMAP

  2. Diving into the OSI Model

    • Understanding the Seven Layers of the OSI Model

    • The Application Layer and its Responsibilities

  3. Hyper Text Transfer Protocol (HTTP): A Peek into Simplicity

    • Understanding HTTP and its Functions

    • The Simplicity and Vulnerabilities of HTTP

    • HTTP in Action: Wireshark Analysis

  4. Hypertext Transfer Protocol Secure (HTTPS): Fortifying Web Communication

    • Introduction to HTTPS and its Importance

    • The Role of SSL/TLS in Enhancing Security

  5. TLS: Safeguarding Data for All Protocols

    • Understanding Transport Layer Security (TLS)

    • The TLS Handshake Process

    • Application of TLS in Various Protocols

  6. SMTP: Tailoring TLS Security for Email Communication

    • The Function of SMTP in Email Services

    • Implementation of TLS in SMTP

  7. MongoDB: TLS Encryption in Database Communication

    • TLS in MongoDB and Data Transmission

    • BSON: The Data Format of MongoDB

  8. Redis: Flexibility in TLS Usage

    • RESP in Redis and Optional TLS Implementation

    • The Impact of TLS on Performance and Security

  9. PostgreSQL (PgSQL): Navigating Data Communication

    • Understanding Data Packets in PgSQL

    • The Option of TLS Security in PgSQL

  10. Securing Data in Protocols: TLS and Its Application

    • Overview of TLS in Different Protocols

    • Challenges in Protocol Security: Man-In-The-Middle Attacks

  11. References

    • HTTP vs HTTPS

    • Further Reading on TLS

Ever wondered about the behind-the-scenes when you connect to a database, make an HTTP request, or check your Gmail? How does a server distinguish your legitimate device from an unauthorised interloper?

Unraveling the Mystery of Protocols

In the world of computer networks, a protocol is like a set of rules or guidelines that dictate the way data is sent and received across a network. These protocols are crucial for ensuring that various hardware and software elements involved in data communication work together seamlessly, despite their different backgrounds.

Consider these examples: HTTP, Simple Mail Transfer Protocol (SMTP), Redis Serialization Protocol (RESP), Post Office Protocol 3 (POP3), Internet Message Access Protocol (IMAP), and more.

Diving into the OSI Model

The OSI model plays a pivotal role in classifying these diverse networking protocols into a well-defined structure.

Why focus on the OSI model? This model is vital as it breaks down network communication into seven distinct layers, with each layer assigned specific responsibilities. Importantly, each layer depends on the ones below it to handle the more fundamental aspects of communication.

Take the Application Layer (Layer 7), for example. It doesn't get bogged down with the nuances of data transport - that's the job of the Transport Layer (Layer 4), where you find protocols like TLS ensuring secure data transmission. This layered approach lets each protocol operate effectively within its domain, without the need to delve into the complexities of the underlying layers.

Before diving deeper into the workings of protocols in contexts like email or database communication, let's start with something more straightforward and accessible: HTTP.

Hyper Text Transfer Protocol (HTTP): A Peek into Simplicity

HTTP, often considered one of the simplest protocols, facilitates the exchange of data in plain text, devoid of encryption or added security layers.

Wireshark image of a HTTP call

Now, let's decode the story revealed by a Wireshark snippet. It unfolds the tale of TCP communication initiation between the client and server, the data transfer process, and the conclusion of communication after data exchange.

Fascinating, isn't it? But is HTTP flawless and universally applicable? Not quite. Despite its simplicity, HTTP has its vulnerabilities. When you visit a website with "HTTP" in the URL, you often encounter a warning message like this:

Why does this warning appear? It's because HTTP is susceptible to eavesdropping, replay attacks, data theft, and various security risks. It lacks the encryption and protection mechanisms necessary to ensure secure data transmission.

Hypertext Transfer Protocol Secure (HTTPS): Fortifying Web Communication
HTTPS (HyperText Transfer Protocol Secure) is an extension of HTTP. It is HTTPS, an extension of HTTP, stands as a more secure alternative. It enhances security by employing SSL/TLS (Secure Socket Layer/Transport Layer Security) to encrypt data during transit.

But how does HTTPS ensure secure communication?

The journey of HTTPS begins much like HTTP, with the same TCP-based communication initiation between the client and server. However, the crucial divergence occurs afterward, where HTTPS introduces the TLS handshake.

**TLS: Safeguarding Data for All Protocols
**TLS, or Transport Layer Security, stands as a protector of data for various protocols, ensuring encryption and decryption of data. To understand why TLS is a vital component in data security, let's delve into how it operates.

In the image presented earlier, we witnessed the process of communication secured by TLS:

  1. Initiation and Cipher Negotiation: The TLS handshake commences when the client sends a "client hello" message, specifying its TLS version, supported cipher suites, and a client-generated random byte string. In response, the server issues its "server hello" message, containing its SSL certificate, chosen cipher suite, and a server-generated random byte string.

  2. Authentication and Key Exchange: Next, the client authenticates the server, utilizing its SSL certificate and a certificate authority. Subsequently, the client sends a premaster secret, encrypted with the server's public key, which the server decrypts using its private key.

  3. Completion and Secure Communication: Both parties collaborate to generate session keys, relying on the client's random data, server's random data, and the premaster secret. This process ensures that both ends compute identical session keys. Following this, they exchange "finished" messages, encrypted with the session keys, thereby establishing a secure, encrypted session.

    In essence, TLS serves as the bedrock of security for various protocols by facilitating encryption and decryption processes. Its robust handshake procedure ensures the establishment of secure encrypted sessions, providing a shield for sensitive data during transmission.

Certainly, let's shift our focus to the importance of encryption keys in various protocols and explore how different protocols, including SMTP, address the need for security.

Now that we've established the concept of secure communication through session keys, it's essential to recognise that not all protocols follow the same approach of "use TLS and be happy." Each protocol has unique requirements and considerations when it comes to security.

Take, for example, email services like "gomailer" that use SMTP (Simple Mail Transfer Protocol). SMTP follows a specific sequence of steps before engaging in TLS encryption. It's important to understand that:

SMTP doesn't immediately jump into TLS for security; instead, it initiates communication and checks if the client is capable of communicating via the protocol. If the conditions are met, it proceeds with TLS to ensure secure data transfer.

In essence, the decision to employ TLS in SMTP occurs at a specific stage of communication, and it's not a universal behaviour across all protocols. Different protocols have their own security mechanisms and initiation procedures tailored to their specific use cases and security requirements. Understanding these variations is crucial in designing and implementing secure communication for various protocols.

SMTP: Tailoring TLS Security for Email Communication**
SMTP serves as the protocol that defines the structure of email messages and the process of transferring these messages between servers, ultimately reaching the recipient's email server. An interesting aspect of SMTP is that the conversation initiates from the server side, which differs from most protocols where communication typically starts at the client side. In SMTP, the server first checks if the client is capable of communicating via the protocol and then proceeds to establish a TLS-encrypted connection.

This reveals a crucial insight: While security is paramount in data transmission, SMTP allows for a flexible approach to when and how security measures are applied. It empowers the sender to choose when to introduce TLS security during the communication process, adapting to the specific requirements of email transfer. In essence, SMTP demonstrates that TLS can be implemented at different stages of communication based on the use-case and security preferences.

MongoDB: TLS Encryption in Database Communication
MongoDB the very popular database uses a some complex protocol to transfer data When you establish a connection between your program and a MongoDB database, a TLS (Transport Layer Security) connection is established to ensure data security. This TLS-encrypted connection becomes the conduit for sharing data.

MongoDB takes a unique approach to data sharing. Instead of transmitting data in plain text like HTTP, MongoDB uses BSON (Binary JSON) as its data format. BSON is a binary representation of JSON (JavaScript Object Notation). To transmit data over the network, this BSON data is further encoded into data packets.

This combination of TLS encryption and BSON data format allows MongoDB to securely and efficiently share data between applications and the database server.

Redis: Flexibility in TLS Usage

Redis, which utilizes the RESP (REdis Serialization Protocol), offers users the flexibility of choosing whether to implement TLS (Transport Layer Security). But why is this choice available, and why doesn't Redis employ security measures by default, as many other applications do? One significant factor is performance optimization.

In high-performance environments where Redis is frequently deployed, minimizing latency is a critical concern. The necessity for TLS largely hinges on the specific security requirements of the application. For instance, if Redis is primarily utilized for caching public data that isn't sensitive, the demand for TLS encryption may be minimal.

So, how does RESP handle data when TLS is enabled? When TLS is activated in Redis, it introduces an additional layer of security. Data packets, including those containing RESP-formatted messages, are encrypted by the client before transmission over the network. Upon receipt, the server decrypts these packets. Notably, this encryption and decryption process is transparent to the RESP protocol itself. RESP continues to operate seamlessly, just as it does without TLS, but the data remains protected throughout transmission, striking a balance between security and performance.

PostgreSQL (PgSQL): Navigating Data Communication

In PostgreSQL (often referred to as PgSQL), specific packets play a pivotal role as they typically contain the actual data or commands sent to the PostgreSQL database server. These packets can encompass a variety of elements, including SQL commands, query results, or database control messages. It's worth noting that certain packets bear distinctive symbols to denote their direction in data communication—">" signifies a packet as a request from the client to the server, while "<R" indicates a response from the server to the client.

Much like Redis, PgSQL also employs symbols to illustrate the direction of data flow, featuring elements like CommandComplete and ReadyForQuery.

Furthermore, similar to Redis, PgSQL offers the option of TLS security as an add-on.So one thing is for sure, these protocols are secure, but are they secure enough to safe?That doesn't seem to be the case.

Securing Data in Protocols: TLS and Its Application

In this discussion, we explored how various protocols implement security, with a focus on TLS (Transport Layer Security). SMTP tailors security for email communication by initiating TLS at specific stages. MongoDB uses TLS to encrypt data transmission, while Redis offers optional TLS due to performance considerations. Similarly, PgSQL employs TLS for added security. However, despite these security measures, the effectiveness of TLS can be challenged by Man-In-The-Middle attacks, emphasising the ongoing need for vigilance in protocol security.


  1. HTTP vs HTTPS.

  2. To undestand TLS more.
